D3 / D3-5
1200 x 1000 x 150 мм
Dimensions L×W×H: 1200 x 1000 x 150 mm
Material: HDPE, Virgin material
Material: HDPE, Virgin material
Temperature stability: -30 °C to +40 °C, briefly up to +90 °C
Weight: 14 kg
Load capacity Static: 5000 kg
Load capacity Dynamic: 1000/1250/1500 kg
Load capacity Racking: 400/1000/1250 kg
Colour: red brown
| Art. No. |
Weight (kg) |
Load capacity (kg) Static |
Load capacity (kg) Dynamic |
Load capacity (kg) High rack |
Colour |
Runners |
Reinforcement profiles |
Central box retainers (mm) |
Rims (mm) |
Anti-slip |
|
83325700 |
14,0 |
5000 |
1000 |
400 |
redbrown |
3,unwelded |
||||
|
83325701 |
14,0 |
5000 |
1000 |
400 |
redbrown |
3,unwelded |
7 |
|||
|
83325730 |
17,0 |
5000 |
1250 |
1000 |
redbrown |
3,unwelded |
3 |
|||
|
83325731 |
17,0 |
5000 |
1250 |
1000 |
redbrown |
3,unwelded |
3 |
7 |
||
|
83325740 |
18,0 |
5000 |
1500 |
1250 |
redbrown |
3,unwelded |
4 |
|||
|
83325741 |
18,0 |
5000 |
1500 |
1250 |
redbrown |
3,unwelded |
4 |
7 |
||
|
83320700 |
15,0 |
5000 |
1000 |
400 |
redbrown |
5,unwelded |
||||
|
83320701 |
15,0 |
5000 |
1000 |
400 |
redbrown |
5,unwelded |
7 |
|||
|
83320730 |
18,0 |
5000 |
1250 |
1000 |
redbrown |
5,unwelded |
3 |
|||
|
83320731 |
18,0 |
5000 |
1250 |
1000 |
redbrown |
5,unwelded |
3 |
7 |
||
|
83320740 |
19,0 |
5000 |
1500 |
1250 |
redbrown |
5,unwelded |
4 |
|||
|
83320741 |
19,0 |
5000 |
1500 |
1250 |
redbrown |
5,unwelded |
4 |
7 |
The D3 / D3-5 Industrial pallet
is a true all-rounder and was specially designed for box applications in the automotive industry.
Characteristics (83325700):
- Available as 3-runner D3 or 5-runner D3-5
- Tare weight of just 14 kg / 15 kg
- Robust construction
- Versatile and easily adaptable to current and future logistics requirements
- All runners have chamfered edges on both sides for ideal use with fork lift trucks
- The D3/D3-5 version with 22 mm outside rims has an inner dimension of 1200 x 1000 mm for box and blister applications
Option:
- Corrosion-protected reinforcement profiles, for load capacities of up to 1.250 kg in high rack
- Rim options: Without, 7 mm, 22 mm, 22 mm outside
- Pop-Ups as interlocking support for stacking of empty pallets
- Anti-slip plugs from top to underside of deck
- Integration of RFID transponders
